Colorized Micrographs

The following micrographs, each imaged in the course of this project, were colorized by utilizing various techniques within Adobe Photoshop. These images are designed to both improve clarity in the sample imaged and to simply be visually appealing.

Electrochemically Deposited Silver Nanoparticles on HAP (100kx)
HAP Side View (20kx)
Excess Silver Deposition on HAP (SE2 20kx)
HAP Side View ( SE2 20kx)
Electrochemically Deposited Silver Nanoparticles on HAP (BSD 50kx)
Electrochemically Deposited Silver Nanoparticles on HAP (BSD 50kx)

Stereo Pair Anaglyph

The following anaglyph was prepared with Adobe Photoshop using two, offset-by-tilt-angle, micrographs. When observed through Red-Blue Anaglyph glasses, the image appears to be 3-Dimensional.

HAP Side View (SE2 5kx)
